Why a bare ballistic panel is a poor window
A thick monolithic laminate stops rounds and does almost nothing else well on an external opening:
It conducts heat. A solid stack of glass and interlayers has no insulating cavity, so on a west elevation it becomes a warm surface radiating into the room all afternoon.
It carries no solar-control coating. Those coatings need a protected surface inside a sealed cavity. On an exposed face they would not survive cleaning and weather.
It creates condensation risk. A cold inner surface in a humid Mumbai monsoon collects moisture.
Building it into a sealed unit addresses all three.
The construction
Two leaves with a sealed, dry cavity between them, exactly like any double-glazed unit — except one leaf is the ballistic laminate.
Normally the inner leaf is rated. This protects the ballistic laminate from weather and cleaning, and frees the outer pane to carry a low-E or solar-control coating on its cavity face.
For an internal threat, the arrangement reverses. A secure room inside a building — a control room, a strongroom lobby — may need the rated leaf facing the interior side of the threat.
Which way round it goes is a question we ask early, because it changes everything else in the build-up.
What you get
Thermal performance comparable to a good double-glazed window, because that is essentially what it is.
Solar control on the outer leaf, which matters far more in Mumbai than heat loss does.
Acoustic performance that is exceptional. A thick laminate has high mass and good internal damping; the sealed cavity adds a second barrier. Where a room needs security and quiet — a boardroom, a control position facing a road — this is the best-performing window we make.
Normal appearance. From either side it reads as a well-made double-glazed window.
Weight and framing
These units are heavy. A ballistic laminate plus a second pane and a spacer puts real load on everything holding it.
Frame section, reinforcement, fixings and any opening hardware are all specified to the finished unit weight and to the threat rating. That is why an insulated ballistic unit is designed as a complete assembly rather than assembled from a glass order and a standard frame.
Opening panels
Possible, and the hardware becomes a large part of the specification. Hinges must carry the weight; locks must be rated for the threat level, because an opening panel’s security is only as good as what holds it closed.
Where a fixed panel will do, a fixed panel is simpler, cheaper and more secure.
Which ballistic leaf
Any of the constructions in the bullet-resistant range can be the rated leaf — laminated glass most commonly, glass-clad polycarbonate where spall or weight matters.
For coatings and glass grades on the outer leaf, see glass options.
